Power Breakout for Camera Top Plates

• Manages your camera accessory power when on a gimbal, tripod or handheld.
• Four 2 pin Lemo Sockets (0B.302) with interchangeable output or input. Distribute power to three accessories from one primary battery source, such as our TB50 Adapters for Movi Pro (recommended).
• Pairs with our Power Expansion Pack and TB50 Hammerhead for regulated power distribution.
• Creates an extra Lemo output when you're in studio mode, great for a SmallHD monitor.
• Simplified cable routing for a cleaner gimbal & camera build and for Quick Mode Changes onset in under one minute!
• Quick Mode Change Ecosystem: Optimise your changeover times onset! We’ve designed the Power Breakout to mount seamlessly to our Camera Top Plates. This means you can use our Quick Release Top Handle and Dual Rod Mount in the same setup as the Power Breakout.

Specs

• Limited to one power source per unit.

• Machined from 6061-T651 aluminium and hard anodised to match top plates.
• Mounts to the Camera Top Plate with 2 x M4x25 countersunk screws (included).
• 0B.302 Lemo sockets are wired Pin 1 - Pin 2 +
• Designed, manufactured and assembled in Australia by Ignite Digi

Input Power Sources

• Ignite Digi TB50 battery adapter with 2 pin Lemo (20-25V) (recommended)
• Ronin 2 Power Hub.
• V Lock/AB plate when in handheld/tripod mode.
• MōVI Pro ACC D tap (12v AUX up to 2A).

Q&A

How do you mount the Power Breakout?

• The power breakout mounts onto our range of Camera Top Plates with 2xM4 by 25mm countersunk screws. We include 4xM4 25mm countersunk screws, providing you with two spare screws.

Does the Power Breakout mount to the ARRI or Tilta Alexa Mini top plate?

• No. Ignite Digi Camera Top Plates have a wider M4 screw spacing than ARRI or Tilta Alexa Mini top plates. We’ve designed our Camera Top Plates with wider M4 spacing to allow enough room for the Movi Dovetail in the middle of the plate.

 Which Lemo Sockets are the input and which are the outputs?

• You can use any of the 2 pin sockets as an input or output, but the Power Breakout can only ever be used with one power source input. Do not input two or more power sources into the Power Breakout.



If you have additional questions regarding the Power Breakout, please email us.
